EmergTape
General Information
EmergTapeä is a special formulation of high-technology polysiloxanes.
This tape is non-flammable, self-extinguishing and binds only to itself without any adhesive. Forms an excellent seal that is weather/water/air-tight when wrapped around electrical connections and connectors, cable and wiring splices, hydraulic hose protection sleeves, duct joints and other electro-mechanical devices. Also used for medical purposes - such as wrapping field splints and wounds as the tape applies tension/pressure to wound dressings and pads without sticking to flesh and hair.
The special silicone formulation of this tape self-fuses (self-amalgamating) when stretched and over-wrapped. Completely flexible at cold temperatures and can be used to +500ºF / +260ºC continuous exposure. Does not support combustion and resists heat, flame, welding splatter, molten metals, solder drips, slag, sparks, Ozone, UV light and contamination.
Can be wrapped over oily or wet surfaces and is an excellent emergency repair tape for hoses and pipes. Used extensively in aviation, marine and industrial maintenance, repair and overhaul operations.
EmergTapeä is a special formulation of high-technology polysiloxanes.
This tape is non-flammable, self-extinguishing and binds only to itself without any adhesive. Forms an excellent seal that is weather/water/air-tight when wrapped around electrical connections and connectors, cable and wiring splices, hydraulic hose protection sleeves, duct joints and other electro-mechanical devices. Also used for medical purposes - such as wrapping field splints and wounds as the tape applies tension/pressure to wound dressings and pads without sticking to flesh and hair.
The special silicone formulation of this tape self-fuses (self-amalgamating) when stretched and over-wrapped. Completely flexible at cold temperatures and can be used to +500ºF / +260ºC continuous exposure. Does not support combustion and resists heat, flame, welding splatter, molten metals, solder drips, slag, sparks, Ozone, UV light and contamination.
Can be wrapped over oily or wet surfaces and is an excellent emergency repair tape for hoses and pipes. Used extensively in aviation, marine and industrial maintenance, repair and overhaul operations.
Easy & Clean to Use
EmergTapeä incorporates a blue marking stripe along its center, making it easy to over-wrap at 50% when taping long lengths. The triangular profile of the tape (thickest in the centre and reducing thickness towards each edge) ensures a smooth finish to the installation with minimum ridging. Easy to remove with a sharp blade while curing or when completely cured and does not leave a gummy or sticky residue the way pressure sensitive adhesive tapes such as standard vinyl electrical tapes or duct tapes do.
EmergTapeä incorporates a blue marking stripe along its center, making it easy to over-wrap at 50% when taping long lengths. The triangular profile of the tape (thickest in the centre and reducing thickness towards each edge) ensures a smooth finish to the installation with minimum ridging. Easy to remove with a sharp blade while curing or when completely cured and does not leave a gummy or sticky residue the way pressure sensitive adhesive tapes such as standard vinyl electrical tapes or duct tapes do.
This tape is 1" / 25mm wide.
Each roll contains 432" / 36' / 10.9m of tape.
Each roll contains 432" / 36' / 10.9m of tape.
How to Install EmergTapeä
Lift off the end of the tape from its backing film and then hold the free end onto what the tape is being installed on. With your other hand which is holding the remainder of the tape roll, moderately pull or stretch the tape while over-lapping the wrap. The stretching action activates the special formulation of silicone rubber with the result of the tape self-binding / self-fusing to itself.
Lift off the end of the tape from its backing film and then hold the free end onto what the tape is being installed on. With your other hand which is holding the remainder of the tape roll, moderately pull or stretch the tape while over-lapping the wrap. The stretching action activates the special formulation of silicone rubber with the result of the tape self-binding / self-fusing to itself.
Highly Resistant to Harsh Environments
EmergTapeä resists fuels, oils, acids, solvents, UV, Ozone, high-heat, flame exposure, molten metal splashes, slag, solder drips & sparks. The proprietary silicone formulation provides optimal thermal dispersion (high thermal conductivity) and also gives this tape its iron-oxide red colour.
EmergTapeä resists fuels, oils, acids, solvents, UV, Ozone, high-heat, flame exposure, molten metal splashes, slag, solder drips & sparks. The proprietary silicone formulation provides optimal thermal dispersion (high thermal conductivity) and also gives this tape its iron-oxide red colour.
Fusing / Bonding Time
EmergTapeä when over-wrapped under tension adheres to itself and fuses, forming a solid protective shield in 24 hours at room temperature or in just 4 hours at +356ºF / +180ºC. The tape starts to self-fuse / self-bond as it is used, and can be re-seated if necessary only within a few seconds of over-wrapping. After just a minute or two it is usually necessary to remove the tape with a knife or scissors.
EmergTapeä when over-wrapped under tension adheres to itself and fuses, forming a solid protective shield in 24 hours at room temperature or in just 4 hours at +356ºF / +180ºC. The tape starts to self-fuse / self-bond as it is used, and can be re-seated if necessary only within a few seconds of over-wrapping. After just a minute or two it is usually necessary to remove the tape with a knife or scissors.
Many Practical Uses
EmergTapeä makes for easy hose and cable bundling, replacing tie-wraps. Excellent for fixing leaks in piping and hoses. Makes a good emergency fan belt. Provides excellent weather protection for outdoor electrical and electronic connections. Great as a first-aid tape to hold splints & bandages in place.
EmergTapeä makes for easy hose and cable bundling, replacing tie-wraps. Excellent for fixing leaks in piping and hoses. Makes a good emergency fan belt. Provides excellent weather protection for outdoor electrical and electronic connections. Great as a first-aid tape to hold splints & bandages in place.
EmergTapeä High Temperature Super Stretch Fusing Tape
for Aviation, Automotive, Marine, Industrial, Electrical & Medical Use. Non-flammable & self-extinguishing.
for Aviation, Automotive, Marine, Industrial, Electrical & Medical Use. Non-flammable & self-extinguishing.
 |
 |
 |
Please ensure you are using Microsoft
Internet Explorer if ordering on-line.
Internet Explorer if ordering on-line.
List Price is $49.95.
Save $15.00 (-30%) and order on-line for $34.96.
Part # AA59163-II-16
Save $15.00 (-30%) and order on-line for $34.96.
Part # AA59163-II-16
Specifications & Standards
EmergTapeä may also be certified to the following specifications upon request (fees apply):
· Commercial Specification A-A-59163 Type II (Previously MIL-I-46852C Type II)
· Military Specification MIL-I-22444C, · Underwriters Laboratories Inc UL-510 · Boeing DMS2186 Type II
· Lockheed Martin MMS J517 & 5-00857 · Safe Flight 59562-5 · Systems & Electronics Inc ES7889
· McDonnell Douglas Helicopter HS5215 · General Dynamics P5384 Type II, · General Electric A50A493 / A50E112 / P5384
· Rohr RMS315 · FAR 25.853 · CSA 22.2
· Premier Farnell Corp 810112 · 83586 · CTB-15
· 608036-1 · P36728
Applicable NSN / NATO / OTAN Numbers: 5970-00-177-1627
EmergTapeä may also be certified to the following specifications upon request (fees apply):
· Commercial Specification A-A-59163 Type II (Previously MIL-I-46852C Type II)
· Military Specification MIL-I-22444C, · Underwriters Laboratories Inc UL-510 · Boeing DMS2186 Type II
· Lockheed Martin MMS J517 & 5-00857 · Safe Flight 59562-5 · Systems & Electronics Inc ES7889
· McDonnell Douglas Helicopter HS5215 · General Dynamics P5384 Type II, · General Electric A50A493 / A50E112 / P5384
· Rohr RMS315 · FAR 25.853 · CSA 22.2
· Premier Farnell Corp 810112 · 83586 · CTB-15
· 608036-1 · P36728
Applicable NSN / NATO / OTAN Numbers: 5970-00-177-1627
